The Hot Dip Galvanizers Association of Southern Africa hosted the twelfth Hot Dip Galvanizing Awards Evening on Friday 23 August in The Ballroom of Montecasino. Thank you to this year’s sponsors – (in alphabetical order) Armco Galvanizers, Bulldog Projects, Giardina, Macsteel Tube & Pipe, Robor Galvanizers, the SA Institute of Steel Construction and Transvaal Galvanisers.

The winning project involved local community participation, transferred skills, is usable and safe, and is aesthetically and environmentally pleasing. Hot dip galvanizing was selected in order to provide a long term maintenance free life; however, just as important was the knowledge transfer from the engineers to the local contractors. The recipient of this years WGS Barnett trophy is the The HA Mafutho Pedestrian Bridge.

The winners of the 2013 Hot Dip Galvanizing Awards are as follows (listed according to categories):

Winner of the Walter Barnett Trophy (Overall Winner) & Infrastructural and Community Development Category:

Project Name: HA Mofutho Pedestrian Bridge

Project Partners:

Client: Kingdom of Lesotho – Ministry of Public Works & Transport
Department of Rural Roads
Consulting Engineer: Royal HaskoningDHV
Geotechnical Specialist: Knight Hall Hendry
Contractor: Guerrini Marine Construction
Hot Dip Galvanizer: Galvatech (Pty) Ltd

Project Detail

The local community at HA Mofutho had to cross the Senqu River using small boats or directly through the river during low flow conditions in order to access the markets for their produce and to find employment.  In 2009, the Ministry of Public Works and Transport appointed Royal HaskoningDHV to plan a footbridge to create a sustainable future for approximately 2 000 people.  Special attention was paid during the design of the footbridge to job creation and the development of the local construction industry.

Those of us who are used to city life take infrastructural development for granted.  But for some, there are isolated rural communities whose quality of life can be vastly improved by relatively small infrastructure developments.  One such example is this suspension bridge in a remote part of Lesotho, which affects some two thousand citizens and replaces rowing boat ferries used to date.

Due to the remoteness of the bridge site, structural steel was favoured over conventional reinforced concrete because it could be manufactured and erected in sections that could be transported by mules and small delivery vehicles and erected by hand as opposed by crane.  The contractors biggest challenge was the logistical problems associated with the construction of a bridge in a remote area.  The steelwork was manufactured and galvanized in Cape Town and transported to Lesotho and concrete was mixed on site by means of volume batching.

Architectural Category: Joint Winners

Project Name: 10111 Radio Control Centre

Project Partners:

Owner / Project Manager: National Department of Public Works
End-User: South African Police Service
Architect / Principal Agent: The Matrix cc Urban Designers & Architects
Structural / Civil Engineer: BVi Consulting Engineers Eastern Cape
Quantity Surveyor: Rousseau Probert Elliot
Electrical / Mechanical Engineers: Palace Technologies
Building Contractor: Pro-Khaya Construction
M&E Contractor: Besamandla (Eastern Cape)
Steel Sub-Contractor: Bay Steel
Hot Dip Galvanizers: Galvanizing Techniques (Pty) Ltd

Project Detail

The use of a limited palette of colours and materials that are used in their raw form is being used in more and more cases by South African architects.  Steel is often hot dip galvanized in order to reflect the steel in its most natural form.  With this project being positioned on an extremely exposed, elevated site, which is highly visible, the judges felt it only appropriate to award this project as the Joint winner of the Architectural Category.

Architectural Category: Joint Winners

Project Name: House in Rooi Els

Project Partners:

Developer:  Brandbild
Architect:  Elphick Proome Architect Inc.
Structural Engineer:  Linda Ness Associates cc
Main Contractor:  Apocalypse cc
Hot Dip Galvanizer & Duplex Applicator:  Cape Galvanising (Pty) Ltd
Paint Supplier:  Sigma Coatings

Project Detail

Designed on the back of a serviette over a plate of calamari in Hermanus, this vacation beach house is carefully crafted to create an extraordinary living experience.  Primary design drivers revolved around minimum intrusion on the fynbos and dunes that carpet the site.  Suspending the house on the dune slope allows the fynbos to be practically continuous under its footprint.

This fully site welded construction has, for corrosion protection, been hot dip galvanized and painted.  With every conceivable modern convenience added through great conceptual architecture and attention to detail between the architect, engineer and contractor, this project proves to be excellent for the promotion of hot dip galvanizing in architectural projects.

Mining & Industrial Category:

Project Name: Ndlovu Roll Over Protection Structure and Falling Object Protection Structure

Project Partners:

Developer / Owner:  Marven Equipment
Designer:  Marven Equipment
Project Manager:  Marven Equipment
Main Contractor:  Marven Equipment
Hot Dip Galvanizer:  Robor Galvanizers
Duplex Coatings Applicator:  Bulldog Projects (Pty) Lt

Project Detail

The duplex coating system of a Roll Over Protection Structure (ROPS) offering additional protection for occupants inside a vehicle in the event of an accident.  Marven’s ROPS was branded “Ndlovu” after the African elephant, strong, robust and the lightest in its class of being a heavy duty, multiple roll over protection structure.  Ndlovu is capable of handling speeds of 120km/h thus enabling additional protection for contractors and employees from the moment they leave their homes and families, on the mines, and back home safely again.

This project is not hundreds of tons; in fact it is only hundreds of kilograms each.  But the market potential is thousands.  The designers decided to ensure a long life by hot dip galvanizing and then the application of duplex coating system provided an aesthetically pleasing product.

Duplex Coating Systems Category:

Project Name:  the House in Rooi Els

Project Partners:

Developer / Owner:  n/a
Designer:  n/a
Project Manager:  n/a
Main Contractor:  n/a
Hot Dip Galvanizer:  n/a
Duplex Coatings Applicator:  n/a

Project Detail

The judges were unanimous, the House in Rooi Els is a prime example of where a duplex coating will ensure not only a great decorative finish in keeping with the architecture, but will ensure a long term corrosion protection system.  What is even better for the duplex system is that because the project took so long to complete, the windy, salt laden moist environment has already given the house as good a test as one could ask for.  Therefore the house was also adjudicated in the Duplex coatings category.

Innovation Category:

Project Name:  Solar Trees at Waterfall Estates

Project Partners:

Developer / Owner:  Century Property Developments
 Architect:  Century Property Development Architect
Consulting Engineer:  C-Plan Civil Engineers
Project Manager:  Century Properties
Steel Fabricator:  Goivota
Hot Dip Galvanizer:  Armco Galvanizers

Project Detail

Situated between Woodmead and Kyalami lies one of the largest estates to be developed within the South African property market. Energy requirements are of paramount importance when considering any form of property development, with clean and renewable energy being considered as first prize when planning the development of property and related energy requirements.

This project is based on the use of a free clean energy source of nuclear fusion to produce the electrical energy to power one of the sectional gatehouses found on the estate.  The architect has cleverly turned the use of hot dip galvanized solar collector panels into a feature referred to as Solar Trees.  The total energy requirement for one of the gatehouses at the estate has been provided by three such solar trees.

The judges were wowed – what a simple, but great idea!  Surely because of their function they are exposed to the elements; the use of hot dip galvanizing as the long term maintenance free corrosion protection system almost guarantees that this is something we are sure to see more of.

A great innovation, with the spin off of a new market for hot dip galvanizing, this is a deserving winner of the innovation category and it is hoped we see many more in the future.

The Association would like to use this opportunity to thank the sponsors for supporting this event and to congratulate the winners of the various categories.  Thanks should also be extended to the members of the Association, without whom events such as the Awards Evening would not be possible.

CLICK HERE TO VIEW THE 2013 HOT DIP GALVANIZING AWARDS GALLERY
